RAVENOL AWD-H Haldex Fluid is a special high-performance product engineered for use in Haldex’s Allrad, Quattro and 4motion powertrains and is specially engineered for use with all-wheel drive powertrains with Haldex couplings, such as those in in Audi, Volkswagen, Seat, Skoda, Vauxhall, Land Rover and Volvo vehicles.

The lower the dynamic viscosity, the better. The Haldex clutch will begin to work faster, the oil will circulate more quickly and there is no wear caused by a low temperature start. With regard to the parameters for dynamic viscosity at minus 40 °C, RAVENOL AWD-H Fluid delivers 270,63% higher performance than the original oil VW G 060 175 A2

​​​​​​How the Hadlex Coupling operates:

The Haldex Coupling is a very sophisticated piece of engineering and it needs to be looked after with regular Haldex oil changes. The axle closest to the engine is constantly powered. All-wheel drive powertrains with a Haldex coupling automatically direct engine power to the other axle where required, without any intervention from the driver. The Haldex coupling, a separate component to the rear final drive, but directly attached to it,  is a submerged, multi-plate, wet clutch system that engages upon slip and transfers power to the rear final drive. The system is computer controlled with very fine engineering tolerances. If the Haldex oil is dirty, it can damage other components and affect performance. Dirty Haldex oil can overheat the coupling or cause the clutches to burn out. It can also burn out the Haldex Pump and will lead to loss of rear drive and eventual failure.Application:

RAVENOL AWD-H Haldex Fluid is suitable for use with all-wheel drive powertrains with Haldex couplings, such as those in Audi, Volkswagen, Seat, Skoda, Vauxhall/ Opel, Land Rover and Volvo vehicles. The Haldex oil should be changed every 37,500 miles in order to avoid damage to the powertrain. Please be aware that as the opening on the coupling may be different sizes on different vehicles, you may need to trim the nozzle down in order to get a tight fit when using the 300ml size.

Recommended:

• Volkswagen VW G 052 175 A2
• GM 93165387
• Land Rover LR 054941 (Haldex-Fluid from 2011-2014)
• Land Rover LR 003136 (Haldex-Fluid from 2011-2014)
• Opel 19 40 057
• VW G 052 175 A2
• VW G 055 175 A2
• VW G 060 175 A2
• Volvo 31367940

RAVENOL AWD-H Haldex Fluid offers:

• An excellent flow behaviour at low temperatures
• High, stable viscosity index
• Very good oxidation stability
• Reliable protection against wear, corrosion and foaming
• Excellent coefficient of friction constancy
• High thermal and oxidative stability
• Excellent cooling ability
• Improved shear stability

IF YOU ARE UNSURE OF THE COMPATIBILITY OF THE ITEMS, PLEASE DO NOT HESITATE TO CONTACT US WITH YOUR VEHICLE’S REGISTRATION NUMBER (UK) OR VIN / CHASSIS NUMBER (INTERNATIONAL). PLEASE BEFORE OR AFTER A PURCHASE SEND US YOUR VEHICLE’S DETAILS, SO THAT WE CAN CHECK IF THE PARTS ARE CORRECT FOR YOUR VEHICLE BEFORE DISPATCHING. WE ARE HERE TO HELP!
